When your Bizerba scale starts acting like an enraged toddler and refuses to get along with you or staff, putting it in a timeout unfortunately won’t solve the problem. Whether it's screaming error codes, not using its words or has stopped cooperating altogether, we have a cheat sheet on Bizerba scale troubleshooting and error codes to help you get to the bottom of its tantrum.
Bizerba Scale Error Codes: NCR 7870
These troubleshooting and error codes correspond to Bizerba NCR 7870 model scale.
Issue | Cause | Solution |
Error Code 5 | The scale has drifted | - Double check there is nothing on the scale
- Remove any objects that have lodged underneath the top plate
- Push Reset/Scale Zero button
- Turn the unit off and on
- If the error code persists, please contact an authorized service agent
|
Error Code 4 | There is a possible error |
Press the Zero button. If error priests, please contact an authorized service technician
|
Error Code 4 (during calibration) | The scale experienced movement or vibration during its calibration |
Recalibrate your scale on a stable surface, ensuring you don’t bump or move the scale while weights are present
|
Blank Display | The top plate is stuck | - Check that the top plate and checkstand don’t hit any external objects during the operation
- Remove any objects that have lodged underneath the top plate
- Push the reset/scale button
|
Recurring Error Codes | The +VDC is unstable |
Please contact an authorized service technician
|
Note: These error codes do not pertain to the NCR 7870-4000. To service this scale, please refer to its manual or contact an authorized service technician.
Scanner Troubleshooting Chart
Issue | Indicator Light | Tone | Cause | Solution |
Scanner not working
|
Red off Green off
|
Off |
There is no power
|
Make sure scanner is plugged into the proper power outlet
|
Scanner not working
|
Red flashing Green flashing
|
Off |
The scanner is in sleep mode
|
Wave something in front of the motion detector
|
Scanner not working
|
Red flashing
|
Off |
- IBM 468x and scanner is offline
- The host terminal has sent a “disable scanner” command
| - Check that the IBM terminal is off
- Check that the IBM terminal recognizes the scanner you
- Check that the interface cable is properly connected
Scanner not reading tags
|
Scanner not reading tags
|
Red on
|
Off |
There is an internal failure
| - Turn the circuit breaker to the scanner on and off
- If the problem persists, please contact an authorized service technician
|
Scanner reading only two tags
|
Red on
|
Off |
The scanner is not talking to the host terminal
| - Check that the host terminal is working correctly
- Check that the interface cable is properly connected
|
Voice Messages Troubleshooting Chart
Issue | Cause | Solution |
No voice messages | The scale does not come with the voice messaging feature | - Power scale off and on
- Scan the Diagnostic Mode tag
- Scan the Hex 4 and Hex A tags
- The firmware version will appear
Note: The firmware version must be 497-0301951 or higher to have the voice messaging feature
|
No voice messages | The voice messages option is turned off | - Turn scale off and on
- Scan the Programming Mode tag
- Scan the Hex 3, Hex 2 and Hex D tags
|
Bizerba Scale Error Codes: iS10 & SC II Series
Models | Issue | Cause | Solution |
iS10 & SC II Series
|
Blank display
| - The scale is not plugged in
- The scale is not turned on
- The display setting’s brightness or contrast are too low
| - Plug in power cord to the correct outlet
- Press standby/reset key
- Turn on scale
- Change display settings
|
iS10
|
Only lower half of screen displays
|
The scale is in its underload range because the preload is missing or the platter is stuck
|
- Properly install the load plate
- Remove any foreign objects touching or below the load plate
- Reset scale to zero
|
iS10
|
Only upper half of screen displays
Printer doesn’t work
|
The scale is in its overload range because the scale’s weighing capacity has been exceeded
| - Remove the item from the load plate
- Level the scale
- Turn scale on and off
|
iS10 & SC II Series
|
Printer doesn’t work |
- The print bar is open
- The receipt or label paper is jammed or misinstalled
|
- Close the print bar
- Check that the receipt or label paper is properly seated
|
iS10
|
Weight value is fluctuating | - The load plate is not seated correctly
- External objects are touching the scale
- The scale is dirty
- The scale is not level
- Vibrations or a draft is interfering with the readings
- The item was moving during its weigh-in
| - Make sure load plate is seated correctly
- Remove external objects
- Clean the scale
- Level the scale
- Move the scale to a more stable location
Note: Call Bizerba customer service to change the parameter settings |
iS10 & SC II Series
|
Incorrect weight value
| - The item is incorrectly seated on the scale
- An external object is interfering with the scale’s readings
| - Place item in the center of the scale
- Make sure there is no other objects touching the scale
|
iS10
|
Er20851 |
The digital load receptor has been disconnected
| Check that the digital load receptor is properly connected |
iS10
|
Er22692 Er22699
|
The computer authentication failed
|
Turn scale on and off
|
iS10
|
Er22693
|
The calibration data does not match the connected load cell
| - Connect the load cell used to calibrate the scale
- Recalibrate the scale with a new load cell
|
iS10
|
Er22694
|
The CPU timed out
|
Turn scale on and off
|
